- Network DSP Amplifier With Volume Control
- 16 Channels x 100 Watts into 8 Ohms (All Channels Driven)
- 16 Channels x 200 Watts into 4 Ohms (All Channels Driven)
- 8 Bridgeable Channels of 400 Watts into 8 Ohms
- Built-In Speaker Optimization Profiles
- Ethernet Port for Status Monitoring, Source Switching, and 12 Volt Trigger Control
- Network Programmable Graphic & Parametric Equalization with User Memories
- Assignable Names for Amplifiers & All Zones
- Digital Signal Sense
- Master 12 VDC In/Out Trigger
- Programmable Electronic Crossover for Local Subwoofer Applications; Subsonic Filter
- AudioControl LightDrive™ Anti-Clipping Speaker Protection
- Local Inputs with Pass Through/Loop Outputs
- Dual Analog Bus Inputs
- Compact 2 U Rack Space (Includes Rack Mount Brackets)
- Commercial or Residential Installation Compatible
The Director® M Series feature on-board digital signal processing, graphic & parametric equalization by zone, network monitoring and programming, local and bus inputs, plus the addition of volume control, channel/zone grouping and zone audio presets. They also allow individual channel and zone selection via standard TCP/IP, delivering incredible power and AudioControl’s legendary audio performance.
 |  |  |
 |  |  |
Two digital inputs and outputs are both accessible in the matrixing so that any one of the input sources can be routed through the digital outputs. These digital outputs can be connected to other CM Series, The Director M or D Series or Architect digital inputs so that multiple amplifiers can receive any signal from any of the inputs.
AudioControl has partnered with a growing number of prominent architectural loudspeaker manufacturers to implement speaker performance profiles directly accessible from The Director® D Series onboard DSP. Each speaker manufacturer has provided critical performance data to AudioControl, enabling tailored profiles to be created and stored in software form. Factoring in the individual room acoustics for each home, these speaker profiles achieve an important step in providing the custom integrator the tools to deliver a premium entertainment experience by calibrating systems for their clients.
AUDIOCONTROL SOUND PARTNERS™
 |  |  |  |
 |  |  |  |
| INPUTS Inputs: 8 Stereo Local Inputs, 2 Coaxial/TOSLINK Bus Inputs Input Sensitivity: 1 Vrms for full output, level at maximum Input Gain: 30 dB | CONTROL Remote Power Trigger: +12 VDC or Dry Contact Closure Network Connection/Protocol: 10Base-T Ethernet TCP/IP Communication Protocol: HTTP or Telnet |
| OUTPUTS Amplifier Channels: 16 Power Output (8 Ω): 100 W per channel Power Output (4 Ω): 200 W per channel Power Output (8 Ω Bridged Mono): 400 W Minimum Speaker Load: 4 Ω Preamp Audio Outputs: 8 Stereo Loop Outputs, 2 Coaxial Digital S/PDIF Outputs | WEIGHT & DIMENSIONS Dimensions: 17” W x 15.5” D x 3.5” H (2 U) Weight: 21.0 lbs. (9.5 kg) |
| PERFORMANCE Crosstalk: > 80 dB @ 1 kHz Damping Factor: >300 Signal to Noise: >95 dB, A-wtd, ref full output Crosstalk: >80 dB @ 1 kHz DAC Specifications: 32 to 96 kHz sample rate, 16-/24-bit depth | IN THE BOX The Director Model M6800, Speaker Connectors, Remote Connector, Power Cord, Manual, Warranty |
