Digital to Analog Audio Converter

Description

AVPro Edge's Digital to Analog Audio Converter is an easy-to-use product that converts Coaxial or Optical audio signals into analog Stereo (L/R) audio. It can be easily switched between either Coaxial or Optical inputs. Its compact, elegant design and simple LED input status make it easier for users to connect up and use instantly.



Digital to Analog Audio Converter

Product form

  • HDTV Digital Output Conversion
  • 24-Bit Conversion
  • Supports S/PDIF audio at 192kHz/24-bit data for conversion to left and right analog channels
  • Integrated digital interpolator filter and Digital-to-Analog Converter (DAC)

SKU: AC-DAC-CO2

  • Shipped today? Order within: Dec 14, 2024 13:00:00 -0600

Description

AVPro Edge's Digital to Analog Audio Converter is an easy-to-use product that converts Coaxial or Optical audio signals into analog Stereo (L/R) audio. It can be easily switched between either Coaxial or Optical inputs. Its compact, elegant design and simple LED input status make it easier for users to connect up and use instantly.



  • Specs
  • Resources
  • In the Box
Input Ports

1×TOSLINK (S/PDIF Audio)

1×RCA (S/PDIF Audio)

Output Ports2×RCA (Stereo Audio)
Input Audio FormatLPCM 2.0
Output Audio FormatAnalog 2.0
Input Sampling Rates32kHz, 44.1kHz, 48k Hz, 88.2kHz, 96kHz,
176.4kHz &192kHz
Output Level2Vrms
Output Impedance600Ω
ESD Protection

Human Body Model:

±12kV (Air Discharge)

±8kV (Contact Discharge)

Weight30g
Chassis MaterialPlastic
Operating Temperature0˚C - 40˚C/32˚F - 104˚F
Storage Temperature−20˚C - 60˚C/−4˚F - 140˚F
Relative Humidity20 - 90% RH (Non-condensing)
Power Supply5V/1A DC (US/EU standards, CE/FCC/UL
certified)
Power Consumption0.74W
Chassis MaterialMetal
Dimensions (unit only Length/Width/Height)

MM: 64 x 58.3 x 22.2

INCH: 2.52 x 2.3 x 0.87

Dimensions (packaged Length/Width/Height)

MM: 133 x 155 x 90

INCH: 5.24 x 6.1 x 3.54

Weight (Unit) 1.14 LBS (0.7 KG)
Weight (Packaged)0.57 (0.26 KG)



  • Digital to Analog Audio Converter
  • 5V/1A DC Power Adaptor
