AVALON G4

Description

4-Channel Power Amplifier

Using the award-winning Savoy G3 amplifier as a basis, the AudioControl Avalon G4 delivers exceptional detail and clarity thanks to an innovative and highly efficient Class H design that effortlessly achieves 230 watts per channel, all channels driven. The Class H design topology provides superb audio quality and bullet-proof reliability while reducing heat dissipation from a compact form factor. The Avalon G4 also features AudioControl’s LightDrive™ anti-clipping protection circuit, which protects loudspeakers from clipping and distortion even in extreme conditions such as a highly dynamic action movie soundtrack.

The Avalon G4 can be easily configured as a 4-channel amplifier, a powerful 2-channel amplifier, or as a 2.1 solution without any need for DSP management. Each pair of channels features hi/lo/bypass crossover controls, balanced (XLR) and unbalanced (RCA) inputs as well as RCA throughputs to achieve multiple configuration options. The Avalon G4 also features independent channel level controls, remote power control triggers, and audiophile-grade 5-way binding posts.

The Made in USA Avalon G4 has been designed as a perfect match to AudioControl’s home theater processors and is ideally suited for immersive surround formats or as a premium standalone power amplifier for nearly any home audio system.

Read more

AVALON G4

Product form

4-Channel Power Amplifier

  • Four-channel home theater amplifier
  • Award-winning theater amplifier technologies
  • Cool Running Class H Operation
  • Multi-mode operation: 4-channel, 2.1-channel, and high-power 2-channel

SKU: ACP-HPA-A4

  • Shipped today? Order within: Jan 20, 2025 13:00:00 -0600

Login

Description

4-Channel Power Amplifier

Using the award-winning Savoy G3 amplifier as a basis, the AudioControl Avalon G4 delivers exceptional detail and clarity thanks to an innovative and highly efficient Class H design that effortlessly achieves 230 watts per channel, all channels driven. The Class H design topology provides superb audio quality and bullet-proof reliability while reducing heat dissipation from a compact form factor. The Avalon G4 also features AudioControl’s LightDrive™ anti-clipping protection circuit, which protects loudspeakers from clipping and distortion even in extreme conditions such as a highly dynamic action movie soundtrack.

The Avalon G4 can be easily configured as a 4-channel amplifier, a powerful 2-channel amplifier, or as a 2.1 solution without any need for DSP management. Each pair of channels features hi/lo/bypass crossover controls, balanced (XLR) and unbalanced (RCA) inputs as well as RCA throughputs to achieve multiple configuration options. The Avalon G4 also features independent channel level controls, remote power control triggers, and audiophile-grade 5-way binding posts.

The Made in USA Avalon G4 has been designed as a perfect match to AudioControl’s home theater processors and is ideally suited for immersive surround formats or as a premium standalone power amplifier for nearly any home audio system.

Read more

  • FEATURES
  • SPECIFICATIONS
  • RESOURCES
  • Award-winning theater amplifier technologies
  • Four channel home theater amplifier
  • Multi-mode operation: 4 channel, 2.1 channel, and high-power 2 channel
  • 230 watts per channel at 8 ohms; 300 watts per channel at 4 ohms
  • 600 watts at 8 ohms bridged
  • Stable into low impedances
  • Stereo/mono operation
  • Unparalleled Energy Efficiency
  • High Definition BiMOS Outputs
  • Cool Running Class H Operation
  • LightDrive Anti-Clipping Protection Circuitry
  • 5-way Binding Posts
  • Unbalanced RCA inputs with pass through
  • Balanced XLR Inputs
  • Bullet-Proof Reliability
  • Remote 12 volt Trigger
  • Perfect paired with AudioControl’s Maestro M9 or M5 Preamplifiers
INPUTS
Inputs: 4 RCA Unbalanced, 4 XLR Balanced
Input Sensitivity: 1.42 Vrms for full output
Maximum Input Voltage: 2.7 Vrms
Input Impedance: 100 kΩ		CONTROL
Remote Power Trigger: +12 VDC or Dry Contact Closure
OUTPUTS
Amplifier Channels: 4
Power Output (8Ω): 230 watts per channel
Power Output (4Ω): 300 watts per channel
Power Ouput (8Ω Bridged Mono): 600 watts
Minimum Speaker Load: 4Ω		GENERAL
Peak AC Power Draw (full output 8Ω): 1200 watts
Typical AC Power Draw (all channels driven): 400 watts
Protection: clipping, short circuit, thermal, DC offset
PERFORMANCE
Damping Factor: >450
Total Harmonic Distortion: 0.04% (230 watts @ 8 ohms 20 Hz-20 kHz)
Signal to Noise: >102dB, A-wtd ref Full Output
Frequency Response: 10 Hz -20 kHz ±1dB		WEIGHT & DIMENSIONS
Dimensions: 17” W x 16.5” D x 3.5” H (2 U)
Weight: 38.0lbs 17.2kg)
 IN THE BOX
Avalon G4, Power Cord, rack mounting brackets, Manual, Warranty

MANUAL
DATA SHEET
