- Award-winning theater amplifier technologies
- Seven-channel home theater amplifier
- Multi-mode operation: 7-channel, 5.1-channel, 5-channel
- 230 watts per channel at 8 ohms; 300 watts per channel at 4 ohms
- 600 watts at 8 ohms bridged on select channels
- Stable into low impedances
- Stereo/mono operation
- Unparalleled Energy Efficiency
- High Definition BiMOS Outputs
- Cool Running Class H Operation
- LightDrive Anti-Clipping Protection Circuitry
- 5-way Binding Posts
- Unbalanced RCA inputs with pass-through
- Balanced XLR Inputs
- Bullet-Proof Reliability
- Remote 12 volt Trigger
- Pairs perfectly with AudioControl home theater preamplifiers
| INPUTS Inputs: 7 RCA Unbalanced, 7 XLR Balanced Input Sensitivity: 1.42 Vrms for full output Maximum Input Voltage: 2.7 Vrms Input Impedance: 100 kΩ | CONTROL Remote Power Trigger: +12 VDC or Dry Contact Closure |
| OUTPUTS Amplifier Channels: 7 Power Output (8Ω): 230 watts per channel Power Output (4Ω): 300 watts per channel Power Output (8Ω Bridged Mono): 600 watts Minimum Speaker Load: 4 Ω | GENERAL Power Consumption (Standby): < 2 W Power Consumption (Idle): 38W Power Consumption (loud listening level): 367W Power Consumption (maximum): 2100W BTU/Hour Output (Standby): 5.6 BTU/hr BTU/Hour Output (Idle): 129 BTU/hr BTU/Hour Output (1/8th power, loud listening level): 477 BTU/hr BTU/Hour Output (maximum): 2507 BTU/hr Protection: clipping, short circuit, thermal, DC offset |
| PERFORMANCE Damping Factor: >450 Total Harmonic Distortion: 0.04% (230 watts @ 8 ohms 20 Hz to 20 kHz) Signal to Noise: >102 dB, A-wtd ref Full Output Frequency Response: 10 Hz -20 kHz, ±1 dB | WEIGHT & DIMENSIONS Dimensions: 17” W x 16.5” D x 5.25” H (3 U) Weight: 43.0 lbs (19.5 kg) |
| IN THE BOX Savoy G4, Power Cord, rack mounting brackets, Manual, Warranty |
