- Award-winning theater amplifier technologies
- Five-channel home theater amplifier
- Multi-mode operation: 5-channel, 3.1-channel, 3-channel
- 230 watts per channel at 8 ohms; 300 watts per channel at 4 ohms
- 600 watts at 8 ohms bridged on select channels
- Stable into low impedances
- Stereo/mono operation
- Unparalleled Energy Efficiency
- High Definition BiMOS Outputs
- Cool Running Class H Operation
- LightDrive Anti-Clipping Protection Circuitry
- 5-way Binding Posts
- Unbalanced RCA inputs with pass through
- Balanced XLR Inputs
- Bullet-Proof Reliability
- Remote 12 volt Trigger
- Perfect paired with AudioControl’s home theater preamplifiers
| INPUTS Inputs: 5 RCA Unbalanced, 5 XLR Balanced Input Sensitivity: 1.42 Vrms for full output Maximum Input Voltage: 2.7 Vrms Input Impedance: 100 kΩ | CONTROL Remote Power Trigger: +12 VDC or Dry Contact Closure |
| OUTPUTS Amplifier Channels: 5 Power Output (8Ω): 230 watts per channel Power Output (4Ω): 300 watts per channel Power Ouput (8Ω Bridged Mono): 600 watts Minimum Speaker Load: 4 Ω | GENERAL Power Consumption (Standby): < 2 W Power Consumption (Idle): 38W Power Consumption (loud listening level): 263W Power Consumption (maximum): 1500W BTU/Hour Output (Standby): 5.6 BTU/hr BTU/Hour Output (Idle): 129 BTU/hr BTU/Hour Output (1/8th power, loud listening level): 313 BTU/hr BTU/Hour Output (maximum): 1791 BTU/hr Protection: clipping, short circuit, thermal, DC offset |
| PERFORMANCE Damping Factor: >450 Total Harmonic Distortion: 0.04% (230 watts @ 8 ohms 20 Hz-20 kHz) Signal to Noise: >102dB, A-wtd ref Full Output Frequency Response: 10 Hz to 20 kHz, ±1 dB | WEIGHT & DIMENSIONS Dimensions: 17”W x 16.5”D x 5.25”H (3U) Weight: 41.0 lbs (18.6 kg) |
| IN THE BOX Pantages G4, Power Cord, rack mounting brackets, Manual, Warranty |
