Bijou 600

Description

Trendsetting and first-of-its-kind, the Bijou 600 exploits AudioControl’s renowned expertise in high-performance amplifier development to integrate pre-amplifier control and bass management capabilities, plus an audiophile-grade Wolfson digital-to-analog converter, into a compact, 1 U half-rack-mountable chassis, designed to serve secondary zones from afar or be positioned right inside the action.

AudioControl’s Bijou 600 provides dramatic audio quality to improve performance in any localized audio zone. Upgrade the sound of analog or digital television audio, including gaming, by adding the Bijou 600 to external speakers. Improve streamed music sources like SONOS, HEOS, and others by transferring their digital signals for ultra-precise decoding by the onboard Wolfson DAC and amplification by the Bijou 600’s authoritative 100 watts into 8 Ohms or 200 watts into 4 Ohms. Low-impedance stable down to 3.6 Ohms, the Bijou 600 may also be bridged for use as a 400-watt monoblock.

The Bijou 600’s variable volume is controllable either directly or remotely by IR or RS-232, as is source selection between the dual coaxial and TOSLINK digital inputs or the analog input. AudioControl’s patented AccuBASS™ equalization is combined with selectable high-pass and low-pass crossovers for fine-tuning speaker system response to the listening room. A line-level, mono-summed subwoofer output provides added flexibility for remote zone systems. Small in stature at 8.5 x 7.5 x 1.7 inches, TV mounts and rack hardware designed exclusively to facilitate custom installation of the feature-packed Bijou 600 are available from AudioControl dealers.

Designed, engineered, and manufactured for the residential and Pro Audio custom installation markets in the rainforest of the Northwest USA, somewhere North of Seattle, the Bijou 600 is backed by AudioControl’s renowned 5-year warranty.

Read more

Bijou 600

Product form

2.1 Channel Compact Amplifier with Audiophile-grade Wolfson Digital-to-Analog Converter

  • 2 channels with bridged mono and subwoofer mono preamp outputs
  • 100W into 8 Ohms, 200W into 4 Ohms, 400W mono into 8 Ohms
  • RS-232 & IR Control
  • High-quality Wolfson DAC 16-/24-bit, 32 to 192 kHz Sampling Frequencies

SKU: ACP-BIJOU

  • Shipped today? Order within: Nov 21, 2024 13:00:00 -0600

Login

Description

Trendsetting and first-of-its-kind, the Bijou 600 exploits AudioControl’s renowned expertise in high-performance amplifier development to integrate pre-amplifier control and bass management capabilities, plus an audiophile-grade Wolfson digital-to-analog converter, into a compact, 1 U half-rack-mountable chassis, designed to serve secondary zones from afar or be positioned right inside the action.

AudioControl’s Bijou 600 provides dramatic audio quality to improve performance in any localized audio zone. Upgrade the sound of analog or digital television audio, including gaming, by adding the Bijou 600 to external speakers. Improve streamed music sources like SONOS, HEOS, and others by transferring their digital signals for ultra-precise decoding by the onboard Wolfson DAC and amplification by the Bijou 600’s authoritative 100 watts into 8 Ohms or 200 watts into 4 Ohms. Low-impedance stable down to 3.6 Ohms, the Bijou 600 may also be bridged for use as a 400-watt monoblock.

The Bijou 600’s variable volume is controllable either directly or remotely by IR or RS-232, as is source selection between the dual coaxial and TOSLINK digital inputs or the analog input. AudioControl’s patented AccuBASS™ equalization is combined with selectable high-pass and low-pass crossovers for fine-tuning speaker system response to the listening room. A line-level, mono-summed subwoofer output provides added flexibility for remote zone systems. Small in stature at 8.5 x 7.5 x 1.7 inches, TV mounts and rack hardware designed exclusively to facilitate custom installation of the feature-packed Bijou 600 are available from AudioControl dealers.

Designed, engineered, and manufactured for the residential and Pro Audio custom installation markets in the rainforest of the Northwest USA, somewhere North of Seattle, the Bijou 600 is backed by AudioControl’s renowned 5-year warranty.

Read more

  • FEATURES
  • SPECIFICATIONS
  • RESOURCES
  • Compact Amplifier and Digital-Analog-Converter (DAC)
  • Audiophile-grade Wolfson DAC
  • 2 x 100 watts into 8 Ohms, 200 watts into 4 Ohms
  • 400 watts Mono-bridgeable
  • Stable Down to 3.6 Ohms
  • Preamp Volume Control Via Direct and Remote IR and RS-232
  • Source Switching Via Direct or Remote IR and RS-232
  • Includes Remote Control
  • 2 x TOSLINK & 2 x Coaxial Digital Inputs with Analog Stereo Inputs
  • Subwoofer Mono-summed Output
  • AudioControl Patented AccuBASS ™ Bass Response
  • Built-in, Selectable Electronic Crossover Points
  • 3.5 mm Headphone Output
  • 5-way Binding Posts
  • Compact Size at 8.5” W x 7.5” D x 1.7” H
INPUTS
Digital Inputs: Optical TOSLINK x 2, Coax S/PDIF 75 ohms x 2
Analog Inputs: Stereo RCA x 1
Input Sensitivity: 230mV (RCA); 2.0V (Speaker Level)
Signal Sense Trigger Minimum: 10mV (RCA); 100mV (Speaker Level)		CONTROL
12 Volt Trigger Inputs: 1 (mini jack)
IR Inputs: 1 (mini jack)
IR Outputs: 1 (mini jack)
RS-232 Serial Control: Yes
OUTPUTS
Amplifier Channels: 2
Power Output (8Ω): 100W per channel
Power Output (4Ω): 200W per channel
Minimum Speaker Load: 4Ω
Preamp Outputs: Mono RCA Subwoofer, Mono RCA Bridged		GENERAL
Power Consumption (typical usage): 40W
Power Consumption (maximum): 520W
Line Voltage: 100-120VAC/200‐240VAC Switchable
PERFORMANCE
Signal to Noise Ratio: >95dB
Frequency Response: 20Hz-20kHz
Total Harmonic Distortion: 0.09%		WEIGHT & DIMENSIONS
Dimensions: 8.50” W x 7.51” D x 1.73” H
Weight: 6.0lbs (2.7kg)
 IN THE BOX
Bijou 600, RT-1 Remote, Power Cord, Optical Cable, User Manual, Warranty

MANUAL
DATA SHEET
DRIVERS
AUTOMATION TABLE
IR LEARNING
